MULTI SPLIT Outdoor units
Using this system, you can connect from two to five indoor units to an outdoor unit. With the Heiko Multi Split solution, air conditioners comprising the system can be controlled separately, so that different temperatures can be set for each unit. The system allows for cooling or heating of at least two rooms at the same time. The Heiko Multi Split system is provided with a high-efficiency outdoor unit and from 2 to 5 indoor units in various arrangements.
R32 refrigerant
The R32 refrigerant used in air conditioners makes them far more efficient than the appliances operating on the commonly used R410A refrigerant.
Inverter technology
The inverter technology enables economical operation of the system without sudden spikes in compressor frequency, while ensuring energy-efficient and quiet operation of the appliance.
Automatic defrosting
Efficient operation of the MULTI SPLIT system in the heating mode, under difficult weather conditions, is possible with automatic defrosting of the heat exchanger of the outdoor unit.
DC motor
The high-efficiency DC motor with a compact design ensures energyefficient operation of the fan of the outdoor unit. The DC motor, compared to conventional AC motors, ensures lower operation noise of the outdoor unit.
Hydrophilic aluminium film
The special coating of heat exchangers prevents corrosion and extends the service life of the appliance.
-
MULTI SPLIT Outdoor units
Outdoor unit M2T050-D1 M3T070-D1 M5T100-D1 Electrical data Power supply Ph/V/Hz 1/230/50 1/220~240/50/60 1/220~240/50/60 Performance Airflow m3/h 2400 3000 4200 Sound power leve dB(A) 63 66 71 Sound pressure leve dB(A) 53 53 55 Installation Dimensions without packaging (W x D x H) mm 800/275/553 890/340/700 920/372/760 Dimensions with packaging (W x D x H) mm 954/409/625 998/443/770 1036/478/820 Net/gross weight kg 36/39 54/58 66/71 Compressor type Twin Rotary Twin Rotary Twin Rotary Refrigerant R32 R32 R32 GWP 675 675 675 Diameter of liquid pipe mm 2×6.35 3×6.35 5×6.35 Diameter of gas pipe mm 2×9.52 3×9.52 3×9.52+2×12.7 Total pipeline length (max) m 30 60 80 Max level difference m 15 25 25 Reserved refrigerant kg 1.4 1.6 2.4 Total pipeline length without refill m 20 30 40 Amount of extra refrigerant per one metre of pipeline g/m 20 20 20 Operating conditions Cooling (min. – max) °C -10~46 10~46 -10~46 Heating (mix. – max) °C -15~24 -15~24 -15~24 -
Max number of indoor units per outdoor unit
Max number of indoor units per outdoor unit 2 3 5 Indoor units 2 × JS035-D1 3 × JS026-D1 2 × JS026-D1 + JS035-D1 + JS050-C1 Nominal value Capacity Cooling kW (nom. (min. – max.) 5(1.1~5.7) 6.2 9.5 Heating kW (nom. (min. – max.) 5.2(1.6~6.1) 6.8 10.0 Power input Cooling kW (nom. (min. – max.) 1.45(0.35~2.55) 1.85 3.4 Heating kW (nom. (min. – max.) 1.4(0.55~2.8) 2.05 2.8 EER/COP 3.45/3.71 3.3/3.3 2.7/3.2 Seasonal energy efficiency SEER/SCOP 6.50/4.00 6.2/3.8 6.2/3.8 Energy efficiency class (cooling/heating) A++/A+ A++/A A++/A Annual energy consumption (cooling) kW 269 332 537 Annual energy consumption (heating) kW 1645 2012 2889
